Saunders Class 10000 Cleanroom

Saunders sets the standard for precision and cleanliness with our Class 10000 Cleanroom. Engineered to meet rigorous ISO 7 requirements, this cleanroom classification is built for precision-driven applications where contamination control is essential.

What Is a Class 10,000 Cleanroom?

A Class 10000 Cleanroom, also known as an ISO 7 Cleanroom, is a meticulously controlled environment designed to reduce contamination from airborne particles, microbes and other pollutants. It is used in industries like electronics, aerospace, medical device manufacturing and pharmaceuticals, where even minimal particulate matter can affect product quality.

Class 10,000 Cleanroom Requirements

Although the Class 10,000 cleanroom is less restrictive than other cleanrooms, allowing higher particle counts and minimal protective gear, workers must still adhere to specific requirements:

  • The Airborne Particle Limits cannot exceed 352,000 particles per cubic meter, equivalent to 10,000 particles per cubic foot of air (≥0.5 microns).
  • 60 to 90 air changes per hour are required to flush out contaminants and maintain particle levels.
  • High-efficiency particle air (HEPA) is required to remove 99.97% of particles (≥0.5 microns) using an air velocity of 10-15 feet per minute.

Cleanroom Design

Class 1000 Cleanrooms are built to maintain contamination-free environments using an advanced, secure design:

  • Air filtering units are equipped with HEPA filters able to remove particulate matter.
  • The ceiling grid is built from tightly sealed tiles designed to fit securely in the grid, preventing external contamination.
  • The walls are made from non-porous surfaces like vinyl, high-pressure laminates, fiberglass-reinforced plastic, coated steel or aluminum. The wall panels are reinforced with a polystyrene, gypsum or isocyanurate core.

Applications Our Cleanroom Supports

Our Class 10000 Cleanroom supports a wide range of applications including:

  • Medical device converting
  • Cleanroom die-cut parts & adhesives
  • Sterile packaging preparation
  • Precision slitting & laminating for sensitive electronics
  • Kitting & assembly under controlled conditions

Why Choose Saunders’ Cleanroom Services

We pride ourselves on delivering precision and quality to ensure a contamination-controlled environment. We offer everything you need to complete your cleanroom checklist and can help find the right industrial solutions for your team.

Connect with one of our specialists to utilize our cleanroom services today!
